Plumbing System Illustrations for Sales and Service


We have assembled a set of full page (8 1/2″ x 11″) high resolution plumbing illustrations of various residential and light commercial plumbing systems including sinks, faucets, traps, drain lines, toilets, septic systems, venting, pumps, shutoff, valves, and more. One example is shown here. This is a collection of plumbing system service and installation related illustrations. These were designed to help plumbers and sales people with sales and service discussions and training. There are about 12 in all. These are great for a flat rate pricing book, sales presentations, explaining repairs, and training purposes. Show your customers exactly what you are going to repair using these detailed illustrations. You receive jpg and PDF files. These images are not editable like a MS Word document is. You are free to modify them using various image editing software.

Plumbing System Illustrations for Sales and Service
